Price on request
The Merli 28 is a used parallel lathe designed for turning medium and large mechanical components with reliability and precision. Built with a robust machine bed and traditional construction, this lathe ensures good rigidity and stability during machining operations.
With a large turning capacity and a spindle bore of 105 mm, the machine is suitable for machining shafts, flanges, and other cylindrical components. The 2-axis digital readouts improve positioning accuracy and ease of operation, making the Merli 28 an excellent solution for workshops looking for a used conventional lathe for general mechanical machining and maintenance work.
Maximum rotating diameter on the bed: | 900 mm |
Maximum rotating diameter on the cross carriage: | 675 mm |
Distance between the tips: | 2000 mm |
Table dimensions: | 500 mm |
Table type: | Platform with 4 independent jaws |
Spindle nose attachment: | Cam-Lock D1-8 |
Spindle speed: | 1010 rpm |
Spindle bore diameter: | 105 mm |
Cone type: | C.M. 5 |
Overall dimensions: | 4055 x 1360 x 1790 h mm |
Weight: | 6000 Kg |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
