Flat Bed Cnc Lathe Blin BL-CKL61100M-2000
Price on request
Flat Bed CNC Lathe Blin BL-CKL61100M-2000 with C Axis and Motorized Tools
The Blin BL-CKL61100M-2000 is a heavy-duty flat bed CNC lathe designed for machining large and heavy workpieces requiring high rigidity, precision, and versatility. Thanks to its wide bed structure and box guideways with anti-friction material, the machine provides excellent stability and vibration damping during demanding turning operations.
With a maximum swing over bed of 1000 mm and a maximum turning length of 1600 mm, the machine offers a large machining capacity for medium-large components. The maximum admissible workpiece weight of 4000 kg allows safe and stable machining of heavy parts.
The lathe is equipped with a motorized turret with 12 positions (VDI 50), enabling combined operations such as turning, drilling, milling, and tapping within a single setup. The presence of the CS axis with magnetic ring encoder and braking system allows precise spindle positioning and controlled interpolation for complex machining operations.
The spindle bore of 104 mm and C.M. 11 spindle nose allow the use of large chucks and bar stock, ensuring flexibility in workholding and machining applications.
Thanks to its robust construction and multiple configuration options, the BL-CKL61100M-2000 is suitable for a wide range of industrial machining environments requiring both turning and milling capabilities.
Maximum rotating diameter on the bed: | 1000 mm |
Maximum rotating diameter on the cross carriage: | 680 mm |
Distance between the tips: | 2000 mm |
Machinable length: | 1600 mm |
Turret type: | Motorized |
Number of seats in the cabin: | 12 |
X-axis travel: | 520 mm |
Z-axis travel: | 1850 mm |
Spindle nose attachment: | ASA A2-11 |
Spindle speed: | 800 rpm |
Spindle bore diameter: | 104 mm |
Cone type: | C.M. 5 |
Key points: | 6 m/min |
CNC type: | Fanuc, Siemens, Fagor, Gsk, Syntec |
Weight: | 5800 Kg |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
- Bed width: 600 mm
- Maximum swing over bed: 1000 mm
- Maximum swing over cross slide: 680 mm
- Maximum turning length: 1600 mm
- Maximum admissible workpiece weight: 4000 kg
- Spindle bore: 104 mm
- Spindle nose: C.M. 11
- Motorized turret: 12 positions VDI 50
- CS axis with magnetic ring encoder and braking system
- Box guideways with anti-friction material
- Heavy-duty cast iron structure
- Several configurations available
- Machining of large shafts, flanges, and cylindrical components
- Production of heavy mechanical parts for industrial machinery
- Energy, steel, and heavy engineering industries
- Combined turning, milling, drilling, and tapping operations on large workpieces
