Conventional Lathe Merli Clovis 28

Model: CLOVIS 28 X 3000

Brand: MERLI

Type: lathes

Price on request

Description

Used Conventional Lathe Merli Clovis 28

The Merli Clovis 28 is a used conventional lathe designed for reliable and precise turning of medium-sized components. Its sturdy bed and precise guideways provide stability during machining, making it ideal for mechanical workshops and maintenance operations.

Equipped with digital readouts (DRO), the machine allows precise control of tool movement for improved accuracy. The inclusion of a steady rest supports long workpieces, while the manual chuck provides flexibility for different turning operations.

The Merli Clovis 28 is therefore a practical solution for companies seeking a used conventional lathe capable of precision turning of medium-length shafts and cylindrical components.

Technical Specifications

Maximum rotating diameter on the bed:	820 mm
Maximum rotating diameter on the cross carriage:	595 mm
Distance between the tips:	3000 mm
Turret type:	Manual
Number of seats in the cabin:	4
Table dimensions:	500 mm
Table type:	Platform with 4 independent jaws
Spindle nose attachment:	Cam-Lock D1-8
Spindle speed:	1010 rpm
Spindle bore diameter:	105 mm
Cone type:	C.M. 5
Overall dimensions:	5055 x 1360 x 1740 h mm
Weight:	5600 Kg
Type of guides:	Box way
Type of accommodation:	meehanite cast iron
