Price on request
The KDM KTM 12/16M is a used CNC vertical lathe designed for precision turning of medium to large cylindrical components. Its rigid vertical structure provides high stability, making it ideal for machining heavy parts such as flanges, rings, and housings.
Equipped with a Fanuc 18i-TB CNC control, a C-axis, and a live tool ram, the machine allows both turning and milling operations in a single setup. The 16-position tool magazine ensures quick tool changes and efficient multi-operation machining. Manufactured in 2009, the KDM KTM 12/16M is suitable for workshops seeking a used vertical CNC lathe for precise and flexible production.
Maximum turnable diameter: | 1350 mm |
Maximum machinable height: | 1000 mm |
X-axis travel: | -250+1480 mm |
Z-axis travel: | 900 mm |
Table dimensions: | 1250 mm |
Table type: | Platform with 4 independent jaws |
Maximum permissible load: | 6000 Kg |
Spindle speed: | 350 rpm |
High pressure through the spindle: | 20 Bar |
Number of tool-changing positions: | 16 |
C-axis and power tools: | 0,001° |
Key points: | 10 m/min |
Working feed rate: | 3 m/min |
CNC type: | FANUC 18i-TB |
Overall dimensions: | 5085 x 4558 x 5064 h mm |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
