Price on request
The Leopoldo Pontiggia Lepontcontrol D 400 is a used CNC lathe designed for reliable turning operations on medium to large mechanical components. Its robust construction and wide swing over the bed allow the machining of large diameter parts while maintaining stability and precision.
Equipped with an ECS 1802 CNC control, the machine enables programmed turning operations with improved accuracy and repeatability. The 4-position square electric automatic turret allows quick tool indexing, increasing efficiency during machining cycles.
The machine also includes a 3-jaw hydraulic self-centering chuck, steady rest for long workpieces, and a chip conveyor to maintain a clean working environment. The Lepontcontrol D 400 is therefore suitable for workshops looking for a used CNC lathe capable of machining medium to large cylindrical components.
Maximum rotating diameter on the bed: | 800 mm |
Maximum rotating diameter on the cross carriage: | 495 mm |
Distance between the tips: | 3000 mm |
Bed width: | 670 mm |
Turret type: | automatic |
Number of seats in the cabin: | 4 |
Spindle nose attachment: | ASA A2-11 |
Spindle speed: | 1500 rpm |
Useful bar clearance: | 115 mm |
Cone type: | C.M. 6 |
Key points: | 7 m/min |
Working feed rate: | 2 m/min |
CNC type: | ECS 1802 |
Overall dimensions: | 5100 x 1800 x 2000 h mm |
Weight: | 7800 Kg |
