Price on request
The Dainichi F-35 × 1250 is a used CNC lathe designed for precision turning of medium-sized components. Its robust construction ensures high stability and accuracy during turning operations, making it suitable for workshops, maintenance departments, and small series production.
Equipped with a Fanuc 0-T CNC control, the machine offers flexible programming for various turning operations. With a swing over bed of 550 mm and a maximum turning diameter of 350 mm, it can efficiently handle a wide range of mechanical components. The bar capacity of 90 mm and chip conveyor improve productivity and maintain a clean working area.
The Dainichi F-35 × 1250 is ideal for companies seeking a used CNC lathe capable of reliable and precise turning of medium-sized shafts and cylindrical parts.
Maximum rotating diameter on the bed: | 550 mm |
Maximum rotating diameter on the cross carriage: | 400 mm |
Maximum turnable diameter: | 350 mm |
Distance between the tips: | 1270 mm |
Machinable length: | 1250 mm |
Turret type: | automatic |
Number of seats in the cabin: | 12 |
X-axis travel: | 200 mm |
Z-axis travel: | 1320 mm |
Table size: | 315 mm |
Spindle nose attachment: | ASA A2-8 |
Spindle speed: | 2500 rpm |
Spindle bore diameter: | 105 mm |
Spindle power: | 22 KW |
Cone type: | C.M. 4 |
CNC type: | FANUC 0-T |
Overall dimensions: | 1660 x 3710 x 1770 h mm |
Weight: | 6500 Kg |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
