Boring machine T system Lazzati HB 130T

The used Lazzati HB 130T is a high-performance T-type boring machine designed for heavy-duty industrial applications requiring extreme precision and rigidity.

Built in 1997 and equipped with the reliable Heidenhain TNC 426 control, this machine is ideal for complex milling and boring operations on large-scale mechanical components. Featuring a 130mm spindle diameter and a generous 4000mm X-axis travel, it offers the stability and versatility needed for demanding sectors like heavy engineering, aerospace, and energy.

A robust, proven machine that meets EU safety standards and is ready for heavy-duty production.

• Type: T-type boring machine, designed for maximum stability and heavy-duty machining
• Spindle Diameter: 130 mm (ISO 50): Power and rigidity for heavy material removal and precision boring
• Working Range (Axes): X (Longitudinal): 4000 mm, Y (Vertical): 2000 mm, W (Spindle): 700 mm, W1 (Column): 1500 mm
• CNC System: Heidenhain TNC 426 – reliable, intuitive, and an industry standard
• Construction: Hardened and ground guideways with polyamide resin coating to eliminate “stick-slip” and ensure long-term precision
• High-pressure cooling system (internal/external)
• Large rotary table (1500×2000 mm)
• Complete technical documentation and CE compliance

• Heavy Machinery: Precision machining of large machine frames, gearboxes, and structural elements
• Energy Sector: Production of housing components for turbines, pumps, and large valves
• Mold & Die: High-precision boring and milling for large industrial molds
• General Heavy Engineering: Versatile operations for large steel or cast iron components
