Bed type vertical milling machine Phoebus ST 1200 – Fixed Head
Price on request
Bed Type Vertical Milling Machine Phoebus ST 1200 – Fixed Head
The Phoebus ST 1200 is a bed type vertical milling machine with fixed head, designed for precision machining and reliable production of mechanical components. Its solid mechanical design and high-quality components ensure excellent rigidity, accuracy, and long-term durability.
The machine is equipped with square hardened and precision ground sliding guideways with “V” profile, providing high stability and smooth movement during machining operations. Precision ballscrews on the X, Y, and Z axes guarantee accurate positioning and repeatability, making the machine suitable for demanding milling tasks.
The fixed head configuration ensures strong structural rigidity, particularly beneficial during heavy cutting operations. The quick pneumatic drawbar system allows rapid and efficient tool clamping, reducing setup times and improving productivity.
To maintain optimal machine performance, the milling machine is equipped with an automatic centralized lubrication system, ensuring proper lubrication of all sliding components. A chip coolant tank supports efficient chip evacuation and improved cooling during machining.
The machine is powered by original Yaskawa servomotors and drives on the X, Y, and Z axes, delivering precise axis control and dynamic performance. The Z axis motor and drive configuration allow it to function as a fully controlled working axis, improving machining precision and operational flexibility.
For improved safety and coolant containment, the machine can optionally be equipped with a full perimeter enclosure with chip collection tank and front access doors.
X-axis travel: | 1230 mm |
Y-axis travel: | 580 mm |
Z-axis travel: | 660 mm |
Table dimensions: | 1470 x 350 mm |
Spindle nose attachment: | ISO 50 |
Spindle speed: | 1500 rpm |
Weight: | 4600 Kg |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
- X axis travel: 1230 mm
- Y axis travel: 580 mm
- Z axis travel: 660 mm
- Precision ballscrews on X, Y, and Z axes
- Square hardened and precision ground guideways with “V” profile
- Fixed head configuration for increased rigidity
- Quick pneumatic drawbar for tool clamping
- Automatic centralized lubrication system
- Chip coolant tank
- Yaskawa servomotors and drives on X, Y, and Z axes
- Optional full perimeter enclosure with chip collection system
- Precision milling of mechanical components
- Toolroom and maintenance machining
- Production of small and medium mechanical parts
- Operations such as milling, drilling, boring, and tapping in general mechanical engineering workshops
