Price on request
The Tiger TFA4 is a used CNC bed type milling machine designed for precision milling operations on medium-sized mechanical components. Its rigid construction ensures stability and reliability during machining, making it suitable for mechanical workshops and general engineering applications.
Equipped with a SELCA 3045 CNC control, the machine allows precise programming of milling operations. The universal manual head with hydraulic tool clamping provides flexibility for machining at different angles, while maintaining secure tool positioning during operations.
The machine is also fitted with a cooling system and complete CE-compliant fairing, ensuring safe operation and efficient cooling during cutting processes.
The Tiger TFA4 is therefore a practical solution for companies looking for a used bed type milling machine capable of versatile and precise machining tasks.
X-axis travel: | 1600 mm |
Y-axis travel: | 700 mm |
Z-axis travel: | 1000 mm |
Table dimensions: | 1900 x 600 mm |
Maximum permissible load: | 2000 Kg |
Head type: | Manual |
Spindle nose attachment: | ISO 50 |
Spindle speed: | 3000 rpm |
Key points: | 10 m/min |
Working feed rate: | 3 m/min |
CNC type: | SELCA 3045 |
Total power: | 20 KW |
Overall dimensions: | 5000 x 3100 x 2750 h mm |
Weight: | 9000 Kg |
Type of guides: | Box way |
Type of accommodation: | meehanite cast iron |
